PERFORMANCE:
This machine is suitable for hot stamping anodized aluminum onto variouspaper products, plastic sheets, and various high-end and fine printed materials.lt can perform concave convex hot stamping and flat hot stamping on thismachine to obtain three-dimensional, exquisite, and beautiful packaging anddecoration products.
|
TECHNICAL SPECIFICATIONS： |
|
|
Model number |
JX-1040C |
|
Max.Sheet Size |
1040x750mm |
|
Min.Sheet Size |
390x320mm |
|
Max.Foil Stamping Size |
1010x720mm |
|
Applicabe Paper Range |
120-1500g/m2cardboard, corrugated board thickiness<4mm,Plastic0.1-2.0mm |
|
Min.Waster Size Widtgh |
8mm |
|
Max.Mechanical Speed |
4800sheets/h |
|
Max.Foli Length |
480mm |
|
Total weight |
9T |
|
Pressure |
200T |
|
Dimensions |
4600x2250x1900mm |
|
Total Power |
34KW |
|
Heated System Zone |
12 |
|
Stamping Temperature Range |
0°-200° |
|
Foil Feeding shaft |
2V/3V |
|
Air Compressor |
0.8Mpa≥0.6㎡ min |
|
Max.Feeding Pile Height |
1400mm |
|
Max.Delivery Pile Height |
1000mm |
